Product Description

EVH Limited Edition Wolfgang Special Striped Series, Ebony Fingerboard, Red, Black, and White, Aged

Loaded with player-oriented features and iconic style, the Limited Edition Wolfgang Special Striped is a highly-responsive and huge-sounding instrument that was born to crank out some serious rock.

Sporting an eye popping aged striped finish, Red with Black and White Stripes and distressed chrome hardware, the Wolfang Special Striped features a basswood body with arched top, robust graphite-reinforced quartersawn maple neck – carved and rolled to EVH’s exacting specifications and a speedy 12″-16″ compound radius ebony fingerboard with 22 jumbo frets for facilitating energetic riffing and blazing leads. A heel-mount truss rod adjustment wheel also makes for quick and easy neck relief tweaks, a feature guitar techs everywhere will thank you for.

The crystal clear custom-designed EVH Wolfgang Humbucking pickups are mounted directly to the body, supplying girth and sparkle, as well as near-endless sustain to power chords and melody lines.

Every component of this guitar has been selected and positioned for high-speed playing. The low-friction volume knob lets you perform speedy violin-like volume swells with ease while the tone knob resists easy turning – avoiding unwanted tonal shifts as your picking hand flies furiously across the strings. The rock-solid EVH-branded Floyd Rose® locking tremolo bridge combines with the Floyd Rose locking nut to maintain precise tuning, no matter how insane your whammy-bar histrionics get. The EVH D-Tuna® retunes to Drop-D and back with strict accuracy at the mere flick of a finger, making this the only guitar you’ll need onstage.

Specifications:

Body

• Body Material: Basswood
• Body Shape: Wolfgang
• Body Finish: Satin Lacquer

Neck

• Neck Material: Quartersawn Maple
• Neck Finish: Hand-Rubbed Satin Urethane
• Neck Shape: Wolfgang Backshape
• Neck Construction: Bolt-On with Graphite Reinforcement
• Neck Thickness: .805″ at 3rd Fret, .890″ at 12th Fret
• Scale Length: 25.5″ (648 mm)
• Fingerboard Material: Ebony
• Fingerboard Radius: 12″ to 16″ Compound Radius (304.8 mm to 406.4 mm)
• Number of Frets: 22
• Fret Size: Jumbo
• Position Inlays: White Pearloid Dot
• Side Dots: Pearloid
• Nut: Floyd Rose R2 Locking
• Nut Width: 1.625″ (41.3 mm)
• Nut Material: Floyd Rose R2 Locking
• Truss Rod: EVH-Branded with Wheel
• Truss Rod Adjustment: Heel-Mount Truss Rod Adjustment Wheel
• Headstock: EVH Wolfgang

Hardware

• Bridge: EVH-Branded Floyd Rose Locking Tremolo with EVH D-Tuna
• Bridge Mounting: 2-Point Modern
• Tremolo Block: Brass
• Tremolo Arm: Floyd Rose 1000 Series Locking
• Tuning Machines: EVH-Branded Gotoh
• String Trees: Floyd Rose Retainer Bar
• Hardware Finish: Chrome
• Pickup Covers: Black
• Control Knobs: Black Knurled with White Indicator
• Switch Tip: Black
• Strap Buttons: Oversized

Electronics

• Bridge Pickup: Direct Mount EVH Wolfgang Humbucking
• Neck Pickup: Direct Mount EVH Wolfgang Humbucking
• Pickup Configuration: HH
• Controls: Volume (500K EVH Bourns Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH Bourns High Friction Pot)
• Switching: 3-Position Toggle
• Position 1: Bridge Pickup
• Position 2: Bridge and Neck Pickups
• Position 3: Neck Pickup

Additional Info

• Strings: EVH Nickel Plated Steel
• String Gauges: .009 – .042

Accessories

• Included Accessories: Tremolo Arm, Hex Keys & User Manual
• Truss Rod Wrench: 2.5 mm Hex
