All the standards - Chorus, Flanger, Phaser as well as Rotary, Tremolo, and Vibrato are there. Also included is the unique Undulator effect from the H8000 and a RingMod that lands somewhere between ring modulation and synthesis. The dedicated SLOW/FAST footswitch for ramping the LFO rate comes in handy. LFO rates can also sync to Tap Tempo and MIDI clock
Features
Modulate your Modulator: Two LFOs create rich expressive modulation effects.
- 100 Presets
- Studio Quality Sound
- Instant Program Change
- Real-time control with 10 knobs, MIDI or expression pedal
- Tap Tempo and MIDI Clock Sync/Generate
- True Analog Bypass
- Rugged cast metal construction
- Metal footswitches for instant Preset access
- Mono or Stereo operation
- Guitar or Line Level Inputs and Outputs
H9 Control
The H9 Control app provides remote control access of all Eventide effects pedals. With H9 Control, you can manage parameters, presets and settings with an easy to use interface. Get instant access to over 500 presets that push the boundaries of delay, reverb, pitch-shifting, modulation, distortion and more. H9 Control is available on Android, iOS, Mac and PC.
Signature Chorus and Modulation
ModFactor includes the following Eventide signature stereo or mono effects:
Phaser
|
Chorus
|
Wah
|
Flanger
|
ModFilter
|
Vibrato
|
Rotary
|
Tremolo
|
Undulator
|
Ring modulator
|
Specifications
| Input 1 (mono) | ¼ inch mono phone jack |
|---|---|
| Input 2 | ¼ inch mono phone jack |
| Output 1 (mono) | ¼ inch mono phone jack |
| Output 2 | ¼ inch mono phone jack |
| Expression Pedal | ¼ inch mono phone jack |
| Aux Switch | ¼ inch stereo phone jack |
| USB | Type B Socket. Use 2.0 cables only. |
| MIDI In | Five pin DIN (Female) |
| MIDI Out/Thru | Five pin DIN (Female) |
| AC Adapter Jack | US Power Supply included |
| Input Impedance | 500K ohms |
|---|---|
| Output Impedance | 470 ohms |
| Recommended Load Impedance | 10K ohms or greater |
| Power | 9VDC, 500mA, Tip hot (+) |
|---|---|
| Dimensions | English: 4.8" (H) x 7.5" (W) x 2.12" (D) Metric: 122 (H) x 190 (W) x 54 (D) mm |
| Weight | 2.15 lbs, 1kG |
