Lauten Audio Black Series LA-320 Large Diaphragm Tube Condenser Microphone
TWIN-TONE TUBE CONDENSER
FEMALE & MALE VOCALS // ACOUSTIC GUITAR // DRUM ROOM // PIANO
PRO QUALITY WITHOUT THE PRICE TAG
The LA-320 is a twin-tone tube condenser that blends vintage color with modern clarity and balance. This sonically flexible tube design is equipped with two dedicated filters for analog sound-shaping at the source, a USA made JFET for impactful, present sound, and a dual triode vacuum tube with vintage-inspired transformer for harmonic balance and warmth. Ideal for use of female and male vocals as well as stringed instruments and percussion, the LA-320 provides professional quality sonics at an accessible price.
ANALOG SOUND SHAPING
The LA-320 is crafted with two dedicated filters that allow you to shape sounds at the source. This helps remove the need to change out microphones in order to get the sound you want. Capture vocals with presence and punch or remove harshness while adding warmth to an overly bright acoustic guitar at the flip of a switch.
The capsule of a microphone captures music’s most meaningful moments and converts them into electricity with relentlessly unforgiving results. Our hand-tuned 32mm capsule provides a silky, vibrant timbre without the harsh or gritty top-end often found in affordable microphone designs. This makes the LA-320 a powerful choice for delicate and dynamic sounds alike.
The LA-320 signal path includes a dual triode vacuum tube, USA made JFET, and a vintage-inspired output transformer that puts the finishing touches on every sound that passes through it's copper windings. The result is a clear and balanced, professional quality sound at a truly accessible price.
SPECIFICATIONS & DIAGRAMS
- Type: Transformer balanced tube condenser
- Capsule: 32mm pressure gradient
- Polar Patterns: Cardioid
- Freq. Response: 20hz - 20khz
- Dynamic Range: 120dB Minimum
- Max. SPL: 0.5% THD @ 1000hz: 130dB
- Impedance: <200ohms
- Self-Noise Level: < 17dB-A
- Sensitivity: 14MV/PA <@1khz 74dB SPL)
- Connector: 5-Pin XLR (PSU to mic) + 3-Pin XLR (PSU to preamp)
- Power: Requires included PSU (Switchable to 100V to 240V)
