Product Description

LA-220

PROFESSIONAL QUALITY AT AN ACCESSIBLE PRICE

FEMALE & MALE VOCALS // ACOUSTIC GUITAR // DRUM OVERHEADS

PRO QUALITY WITHOUT THE PRICE TAG

The LA-220 is an articulate and full-bodied FET condenser microphone that punches far above it's weight. This sonically flexible design is equipped with two dedicated filters for analog sound-shaping, a transformer balanced output for classic harmonic saturation and warmth, and an ultra-low-noise USA made JFET for powerful, present sound. Ideal for use on both Female and Male vocals, as well as percussion, the LA-220 puts the classic qualities of beloved vintage microphones into an accessible package ideal for both home and professional recording studio environments.

FLEXIBLE SOUND

Immediate analog sound-shaping comes courtesy of the LA-220's two onboard filters. This allows you to shape sounds at the source, removing the need to change microphones to get the sound you want. Add warmth to a bright vocal or remove harshness and boominess from an acoustic guitar at the flip of a switch.

QUALITY CAPSULE

The capsule of a microphone captures music’s most meaningful moments and converts them into electricity with relentless results. Our 32mm capsule provides a modern vibrant timbre without the harshness often found in affordable microphone designs, making it an ideal choice for vocals, acoustic guitar and percussion.

QUALITY COMPONENTS

The LA-220 signal path is populated with high resolution, low distortion polypropylene capacitors and resistors, a US made JFET, and a vintage-inspired output transformer. The result is a powerful, present, mix-ready sound without the high noise floor of many classic microphones.

SPECIFICATIONS & DIAGRAMS

• Type: Transformer balanced FET Condenser
• Capsule: 32mm Pressure Gradient
• Polar Paterns: Cardioid
• Freq. Response: 20hz - 20khz
• Dynamic Range: 120dB Minimum
• Max. Spl: 0.5% THD @ 1000hz: 130dB
• Impedance: <200ohms
• Self-Noise Level: < 15dB-A
• Sensitivity: 16MV/PA -40dB (ODB=1V/PA 1khz)
• Connector: 3-Pin XLR
• Power: Requires 48V Phantom Power
